CK-660C multifunctional plastic cup thermoforming

thermoforming machine 1.THISmachineis designed with most advanced thermoforming technology, a combination of mechanical, electrical and pneumatic components. 2.the wholesystem was controlled by PLC 3.The machine has man-interface operationwhich Electric cooker constant temperature preheat,sends sheet by chain,running by cam, forming by up and down mould and cutting by mould knives. 4.It combines the sheet sending, heating, stretching, forming,cutting into one process. 5.The machine is suitable for PP, PS, ABS, HIPS,PEP material. They are widely used in producing disposable table waresas various kinds of cups like ice cream cups, milk cups, jelly cups, cup,covers, instantnoodle bowls, toy boxes, etc. 6.It can also be used in plastic package in medicine manufacturing, light industry, textile,tourism, etc.... Technical Parameters Suitable material PP,PS,HIPS,PET,PVC Using power 3x380V+N+PE,50HZ Suitable thickness of sheet 0.35-2.2mm sending motor power(Japan Yaskawa) 2.4-4.4kw Air consumption 2600L/min Machine weight 4.0/4.5T Max.forming area 640x330 Max.depth of forming 160-180mm Adjustable length of the trip 100-400mm Productivity efficiency 20-35times/min Rated heating power 67-78kw Regulator pressure mould heating 50A Main machine motor power 7.5kw Water consumption 100L/min Dimension 3300x1650x2250mm Suitable width of sheet 500-630mm Using pressure 0.8Mpa
